1.Inverter rated power: 12000W
2.Instantaneous short-circuit output power: 24000W
3.AC input voltage for mains power: Default 180VAC - 265VAC, can be set to 100VAC - 280VAC
4.Maximum mains power charging current: 70A
5.Output voltage waveform: Pure sine wave
6.Maximum input current of PV: 22.5A + 22.5A
7.Maximum input power of PV: 15000W
8.Maximum charging current of battery: 160A
9.Optimal working voltage of MPPT: 300VDC - 340VDC
10.Voltage range of MPPT: 60VDC - 450VDC
11.Battery rated voltage:48VDC
